RPCT REPL

RPCT is a REPL screened, separable connection system 800 A up to 42 kV.

REPL RPCT screened separable connectors are designed to connect single- and three-core polymeric cables to medium-voltage gas insulated switchgear and other equipment using CENELEC bushings Type C1=630 A and C2=1250 A, specified up to 42 kV.

Made of a highly modified silicone rubber and protected by a thin walled outer conductive screen connected to earth, RPTC connectors are equally suited for indoor and outdoor installation.

Supporting a wide application range, the design incorporates one body and two stress cone adapters to cover all cross-sections from 35 to 300 mm2.

The overall and cut back dimensions are designed to take up minimum space in the terminal box.

RPCT connectors are equipped with a capacitive test point for determining whether the circuit is energised.

A conductive cap protects this test point.

Kits for 3-core applications on request. Contact your local sales representative
